A CLEVIS HANGER provides for sizeable loads to be supported and for an elevation adjustment depending on the pipe diameter. The lower nut adjusts the piping to the proper elevation and the upper nut, when locked into position, prevents loosening due to vibration.

A CLEVIS HANGER consists of a yoke and a support strap made from a shaped Mild steel strip and a joining bolt. 15\u00b0 swing in either direction allows the pipe to easily feed through. The pipe will not pinch when installed. Engineered design aligns bolt holes for quicker overhead installation.

Pipe Hanger

Mild Steel. Also, other materials can be provided on request

1/2 — 30

343°C — 650°F

Plain, Epoxy Coated, Electro-Galvanized, Hot Dip Galvanized, Zinc Flake

As per Size

As per Size

• ANSI/MSS SP-58 & SP-69 (Type 1)
• Federal Specification WW-H-171E & A-A-1192A (Type 1)
